California Institute of the Arts | Walt Disney Modular Theatre

California Institute of the Arts

Walt Disney Modular Theatre


The Modular Theatre – FDA’s first project at Cal Arts – opened more than 35 years ago. Highly innovative for its time, it was designed with four integrated systems, all of them moveable: floor, walls, lights and hoists for flying scenery. These systems offer incredible flexibility for mounting extremely varied types of drama, music and dance performances. The first year of its use, for example, the theatre hosted concerts, dance programs, Shakespearean drama, and modern plays.

The stage floor consists of modules, each four feet square, which are pneumatically adjusted to varying heights. A panelized wall system allows entrances from virtually any point, and a compact, portable winch can be positioned anywhere on the grid. Still actively in use and recently renovated, it is considered one of the most innovative teaching theatres of its kind.

Cal Arts has also just opened and FDA has helped to design REDCAT, a new 200-seat theatre in the lower level of Disney Concert Hall in Los Angeles. Initially, at the request of Cal Arts, FDA studied the feasibility of adding a 500-seat theatre, multimedia performance laboratory, rehearsal and support space to the existing arts complex.

  • Client: California Institute of the Arts
  • Architect: Ladd & Kelsey Architects
  • Completion Year: 1973
  • Location: Valencia, California
  • Capacity: 200 seats

Links


FirstOntario Performing Arts Centre

FirstOntario Performing Arts Centre


After a design competition held in parallel with a similar competition for Brock University’s St. Paul Street building, this brand new downtown performing arts centre completes a $94M arts hub for the City of St. Catharines. The long-planned “town and gown” approach to this project means that the two arts centres will share program space, allowing for interdisciplinary work to emerge organically among the city’s music, drama, and visual arts communities.

At 110,000 square feet, the new Performing Arts Centre features an 770-seat concert hall that will suit both acoustic and amplified events. A flexible theatre and dance venue seats up to 150 patrons, and is planned to serve local theatre arts groups in St. Catharines. A 250-seat recital and rehearsal hall is programmed for orchestral and new music performances, and will double as a lab for music students at Brock University. Other spaces include a 180-seat space for independent films, whose retractable curtains allow it to double as a naturally-lit lecture hall during the day, and a full suite of support spaces optimized to be shared among the performance venues.

  • Client: City of St. Catharines, Ontario
  • Architect: Diamond Schmitt Architects
  • Completion Year: 2015
  • Location: St. Catharines, Ontario
  • Acoustician: Jaffe Holden Acoustics
  • Capacity:
    770-seat concert hall
    300-seat recital hall
    210-seat multi-purpose dance/theatre venue
    199-seat Film House

Links


C. W. Post College, Long Island University | Tilles Center Concert Hall

C. W. Post College, Long Island University
Tilles Center Concert Hall


When the domed roof of its 3,000-seat assembly hall collapsed during a tornado in 1978, the trustees of Long Island University were faced with the decision to rebuild or abandon the facility. They decided to renovate and rebuild, re-designing the hall in the process as a far superior facility for concert music, theatre, and dance.

The building’s architects reconfigured the angled walls within the existing circular shell to better distribute sound in the concert hall. The new focus of the room became a series of reflective, hinged ‘ribbons’ that float from the back of the stage. Other elements in the new kit of parts designed with FDA’s help include a spidery lighting platform, an orchestra pit on a lift, a sprung resilient dance floor and new computer-controlled lighting.

The hall has been hailed for its warm, rich, and enveloping sound by a variety of performers and critics, from conductor Zubin Mehta to diva Marilyn Horne.

  • Client: Long Island University
  • Architect: Mitchell/Giurgola
  • Completion Year: 1982
  • Location: Greenvale, New York
  • Capacity: 3,000 seats

Links


Fairfield Community Arts Center

Fairfield Community Arts Center


The Community Arts Center has been described as one of the “crown jewels” of Fairfield’s Village Green. The 40,000-square-foot Center houses a 250-seat theater, an arts and crafts studio, dance and fitness studio, children’s room, senior lounge, classroom, a multipurpose community/banquet room with a balcony overlooking Village Green Park, and an art gallery. A dramatic two-story, day-lit galleria / lobby welcomes patrons.

“We worked with the entire community to design this one of a kind facility,” said Parks and Recreation Director James Bell. “There is literally something for everyone.”

  • Client: City of Fairfiield
  • Architect: John Poe Architect
  • Arch. of Record: Barker Rinker Seacat Architects
  • Completion Year: 2005
  • Location: Fairfield, Ohio
  • Acoustician: Shell Meye Associates
  • Building Size: 40,000 s.f.
  • Capacity: 250 seats

Links


Yale University – College Arts, Frederick Iseman Theater

Yale University, College Arts
Frederick Iseman Theater


Architect Deborah Berke’s 80,000 sf renovation of and 30,000 sf addition to a 1950s Jewish Community Center originally designed in part by Louis Kahn, is home to the Frederick Iseman Theater (formerly Holcombe T. Green, Jr. Theater) experimental theatre, as well as the School of Art.

At the project’s onset, FDA and the Yale School of Drama faculty sought input from other designers and consultants who are Yale School of Drama alumni. During schematic design, their ideas and suggestions were incorporated into the project. Deborah Berke, FDA, and scenic designer Ming Cho Lee were all instrumental in the planning for this new experimental space, contributing ideas and suggestions about the locations of catwalks, wraparound galleries, and seating plans. Back-of-house planning, along with equipment that includes portable seating riser systems and state of the art stage lighting controls, were among FDA’s contributions to the project.

In 1965, the esteemed Yale School of Drama founded the Yale Repertory Theatre to facilitate a closer relationship between training and practicing professional theatre for students and faculty.

  • Client: Yale School of Drama
  • Architect: Deborah Berke Architects
  • Completion Year: 2000
  • Location: New Haven, Connecticut
  • Acoustician: Jaffe Holden Acoustics
  • Building Size: 112,000 s.f.
  • Capacity: 200 seats

Links


Related Projects


Fellowship Village, Sieminski Theater

Fellowship Village, Sieminski Theater


Fellowship Village Senior Living is in the process of adapting its social environments in an effort to develop a robust in-reach program. Fellowship Senior Living has a population of 450 residents and an increasing demand for programs: invited artists, lectures, in-house productions, and more. The existing 80-seat multipurpose room is inadequate both in capacity and technology for this robust programming. An important first step is the addition of a new auditorium in the heart of the community.

Collaborating with these organizations and KDA, FDA has designed a state-of-the-art auditorium that will provide the setting for the presentation of high-quality, diverse programming in an appropriate setting. Designed for flexibility, the auditorium has 140 retractable seats with the capacity for an additional 100 floor seats to accommodate large productions and events. The retractable seating allows for an entirely open floor for banquet seating.

Two regional performing arts organizations, Berkeley Light Opera Company and Trinity Theater Company, will make this new venue a home for their productions and will bring their audiences with them.

  • Client: Fellowship Village Senior Living
  • Architect: KDA Architects
  • Completion Year: 2019
  • Location: Basking Ridge, New Jersey
  • Capacity: 140 seats

Links


Wolf Trap Farm Park for the Performing Arts Filene Center II

Wolf Trap Farm Park for the Performing Arts
Filene Center II


The acclaimed PBS-TV series “Live From Wolf Trap” originates from this internationally acclaimed outdoor summer theatre, which annually features the world’s best-known concert artists and popular entertainers, such as the New York City Opera and The National Symphony Orchestra.

Completed in 1984, two years after fire destroyed the original outdoor auditorium, Filene Center II is a multipurpose theatre with one of the country’s largest stages. It has substantially enlarged backstage and rehearsal facilities and seating for 3,700 patrons under cover and 3,000 more on the outdoor lawn.

FDA designed and specified equipment for the rebuilt theatre, from stage lighting and rigging systems to an innovative 80,000-pound orchestra shell which can be rapidly set up and completely removed from the stage when not in use.

  • Client: The Wolf Trap Foundation for the Performing Arts
  • Architect: Dewberry & Davis
  • Completion Year: 1984
  • Location: Vienna, Virginia
  • Capacity: 6,700 seats

Links


Drew University, Dorothy Young Center for the Performing Arts

Drew University
Dorothy Young Center for the Performing Arts


The historic Drew University campus in Madison, New Jersey has a new choral and orchestral music hall.

After investigating three design options for the building, the design team and the University chose a 430-seat Recital Hall with a lobby that adjoins the existing arts and theatre wing. The building is adjacent to an historic forest and has views of Drew’s main campus building, Mead Hall. The new hall incorporates state-of-the-art theatrical and acoustical systems, including a center tear-drop shaped acoustical reflector collaboratively designed by FDA, Jaffe Holden Acoustics and FMG Architects. This reflector, lined with concert lighting instruments, can be easily lowered into the house when it requires servicing. Motorized acoustic drapes allow the acoustic qualities of the room to be adjusted for various performance types, including instrumental and pop music.

The room functions both as a teaching and performance space for the University’s music department, as well as a valued new resource for the community and surrounding region.

  • Client: Drew University
  • Architect: Farewell Mills & Gatsch
  • Completion Year: 2005
  • Location: Madison, New Jersey
  • Acoustician: Jaffe Holden Acoustics
  • Capacity: 430 seats

Links


Whitaker Center for Science and the Arts, Sunoco Performance Theater

Whitaker Center for Science and the Arts
Sunoco Performance Theater


The Whitaker Center was the first facility in the nation to link the arts and sciences in one building. The Center houses a 600-seat theater, 200-seat Imax, and a Science Center in a design that affords visitors views from one program area to another to emphasize the link between the disciplines and encourage participation in both.

The Sunoco Performance Theatre has a 664-seat auditorium designed with three levels of seating, none more than 65 feet from the stage. The Broadway-sized stage, fly space, moveable orchestra pit and commodious back-of-house accommodations were designed to meet the production and performance needs of a range of community performing arts groups including the Central Pennsylvania Youth Ballet, Theatre Harrisburg, the Harrisburg Opera Association, and the Concertante Chamber Ensemble.

  • Client: Whitaker Center
  • Architect: Hardy Holzman Pfeiffer
  • Acoustician: Jaffe Holden Acoustics
  • Completion Year: 1999
  • Location: Harrisburg, Pennsylvania
  • Building Size: 130,000 s.f.
  • Capacity: 600 seats

Links


Bushnell Center for the Performing Arts, The Maxwell M. and Ruth R. Belding Theater

Bushnell Center for the Performing Arts

The Maxwell M. and Ruth R. Belding Theater


One of Connecticut’s premier performing arts centers, the Bushnell Center has a 70 year history. Since 1930, many of the world’s most talented singers, dancers and actors – such as Pavarotti, Baryshnikov, Katherine Hepburn and Judy Garland – have performed on its stage.

The Belding Theater was added to the Bushnell Center in in 2001. FDA contributed both to the planning and design of this new, state-of-the-art performance hall. A planning study confirmed the need for an expanded venue, and the resulting expansion added a 900-seat theater to the historic 2,000 seat Art Deco-style auditorium. The new theatre has a stage house 92-foot-wide and 42-foot-deep; beautifully designed orchestra, mezzanine and private box seating, and expanded and enhanced patron and performer amenities.

Other features include a new rehearsal hall that holds special events, VIP patron lounges, and significantly expanded lobbies and restrooms. This new, smaller stage provides local organizations with a high-quality facility for a diverse range of arts and community presentations, and frees approximately 25 dates in the larger hall by transferring programming better suited to presentation in a smaller facility.

  • Client: The Bushnell Theatre
  • Architect: Wilson Butler Architects
  • Completion Year: 2001
  • Location: Hartford, Connecticut
  • Acoustician: Jaffe Holden Acoustics
  • Capacity: 907 seats

Links
